Průmyslový tablet Security LINE EDI14AW, 14“ Win 11 PRO

Kód:

Typ: Nový produkt

Displej 14", rozlišení 1920 x 1200, Windows 11 Professional,16+256GB, CPU Intel® Core™ i5-1235U/, LTE, GPS, WIFI, 2D skener, ovládání v rukavicích

Více informací

Dostupnost: Na dotaz

Tisk

Cena po přihlášení

Popis produktu
Specifikace
Ke stažení

EM-I14A 14palcový ultra odolný tablet Intel Core i5/i7 Windows 11

Procesor Intel® Core™ i5/i7 12. generace.
Grafická karta Intel® Iris® Xe.
Operační systémy Windows 11/10.
14" displej HD&HB.
Otočná rukojeť.
Všestranné rozhraní Thunderbolt 4, USB, HDMI, RJ45, RS232.
Dvojitá baterie 4850 mAh/11,55 V + 1300 mAh/11,1 V, podporuje výměnu za provozu.
Vestavěný NFC, modul otisků prstů, volitelný 2D skener čárových kódů.
Vysokorychlostní Wi-Fi 6.
Rozhraní M.2.
5G/4G.
Bluetooth 5.1.
Vysoká úroveň krytí IP65.
odolnost proti pádu z výšky 1,22 m.
V souladu s MIL-STD-810H.

Specifikace

Typ produktu	14-inch Rugged Tablet
Rozměry	366.2mmx246.9mmx24.8mm
Hmotnost	TBD
Barva produktu	Black
CPU	Intel i5-1235U, TDP15W,2P-Cores,8E-Cores,12threads;Speed: 0.9GHz~4.4GHz Optional：i7-1255U, TDP15W,2P-Cores,8E-Cores,12threads;Speed: 1.2GHz~4.7GHz
GPU	Intel® Iris® Xe Graphics eligible
Paměť	RAM 16GB DDR5 (4800MHz) Optional: 32GB DDR5 (4800MHz) ROM 256GB SSD Optional: 512G 1TB
Operační systém	Windows 11 PRO（HOME, IOT） 64bit Default Language: English Optional: Windows 10 IOT 64bit Windows 10 Pro 64bit Windows 10 Home 64bit
Displej	Type: LCD Size: 14-inch 16:9 Resolution: 1920*1080 Brightness: 1000cd/㎡
Dotykový panel	10-Point Capacitive Screen, G+G; Hardness above 7H; Scratch-resistant; Supports glove touch
Fotoaparát	Front 5.0MP (USB) Rear 8.0MP (USB)
Tlačítka	Power Button 1 Volumn + key 1 Volumn - key 1 Customized key 2（Default: P1 for opening the Control Center, P2 for opening the camera） F key *1 (Barcode scanning)
Reproduktor	Built in 4Ω/3W waterproof speaker *2
Mikrofon	-38dB±3db
Senzor	G-Sensor
Ventilátor	IPX5 fan *1
Baterie RTC	3.0V/220MAH
Zálohovací baterie	Built-in Polymer Lithium-ion Battery, Non-removable 1300mah/11.1V (14.4WH) 1.5H (Default 50% volume, 200 lumens brightness, playing 1080P HD video)
Hlavní baterie	Removable Polymer Lithium-ion Battery, Hot-swappable 4850mah/11.55V（56WH） 8hrs (1080P video playing with system in balanced mode, 320nits screen brightness, 70db volume at 10cm, and WiFi/BT turned off
WIFI	Wi-Fi 6 802.11a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax
Bluetooth	BT5.1 (BLE) class1 Data transmission distance: 10m
4G	4G (M.2 interface, European version ) LTE-FDD: B1/3/5/7/8/20/28 LTE-TDD: B38/40/41
5G	5G (optional) NSA n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/71/75/76/77/78/79 SA n1/2/3/5/7/8/12/13/14/ 18/20/25/26/28/29/30/38/ 40/41/48/66/70/71/75/ 76/77/78/79 LTE LTE-FDD B1/2/3/4/5/7/8/ 12/13/14/17/18/19/20/ 25/26/28/29/30/32/66/71 LTE-TDD B34/38/39/40/ 41/42/43/48
GPS	Supports single GPS or single Glonass, default GPS
I/O rozhraní	USB3.2 1，USB2.0 2
	TYPE-C, Supports Thunderbolt 4
	∮3.5mm Standard Earphone Jack *1
	HDMI 2.0a mini x1
	SIM card *1
	TF card *1
	RJ451 10M/100M/1000M self-adaptive RJ451 10M/100M/1000M self-adaptive (USB2.0), supports Gigabit Ethernet protocol
	RS232 *1, 9 fully functional lines
	DC19V/3.78A ∮5.5mm power interface *1
	12PIN Pogo Pin (USB & Charging) *1
Napájecí adaptér	AC100~240V, 19V/3.78A 71.82W output EU Standard Optional: US Standard
Indikátor napájení	1. Power On: Power indicator remains solid. 2. Power Off: Power indicator turns off. 3. Sleep Mode: Power indicator blinks.
Indikátor baterie	1. Charging: Charging indicator remains solid (red). 2. Fully Charged: Charging indicator remains solid (green). 3. Large Battery Not Connected: Charging indicator flashes quickly (red). 4. Low Battery (10%) Without Adapter Connected: Charging indicator flashes quickly (red)
Odolnost	MIL-STD-810G: 1.22m drop resistance
	Working temperature: -20 °C to 60 °C
	Storage temperature: -30 °C to 70 °C
	Electrostatic Discharge: ±4kV contact discharge, ±8kV air discharge
	Humidity: 95% Non-Condensing
Certifikace	IP65
	CE optional FCC,CCC
	MIL-STD-810H
	Battery: UN3803, MSDS, IEC62133, Aviation, Shipping Report

Ke stažení

Security LINE TABEDI14AW datasheet
